Features:
Stereo hybrid receiver with transistor and tube technology
HDMI input for seamless integration of TV and all connected sources
Selected and previously burned-in tubes for optimum sound
2 x 70 watts RMS output, 250 watts system output
Extensive connections, digital, analogue, MM phono and Bluetooth aptX
Solid metal housing with brushed aluminum front panel and controls
MM phono preamplifier with ultra-low noise operational amplifier incl. subsonic filter
Additional 3.5 mm audio input on the front panel for connecting portable devices
High quality digital-to-analogue converter
High/low tone control, can be switched off via a direct function
Sub out connecting for use of an external active subwoofer
Record Out fixed level output
Technical specificatios:
Output power
Nominal power: 20 Hz – 20 kHz, THD < 1.0%, 4Ω 2 x 70 watts
20 Hz – 20 kHz, THD < 1.0%, 8Ω 2 x 50 watts
Peak power: 1 kHz, 4Ω 2 x 125 watts
Frequency range
DAB/DAB+: 174.928 – 239.2 MHz (Band III)
FM: 87.5 – 108 MHz
Outputs
1 x Sub Out
1 x Record Out
Digital inputs
Supported sampling frequencies: 44.1/48/88.2/96/176.4/192kHz
Supported bit depth: 16/24bits coaxial (cinch) optical (Toslink™)
Bluetooth® input
Bluetooth streaming (5.0) with the high-end audio standard Qualcomm® aptX™
Mains voltage
230 VAC / 50 Hz
Digital inputs
Supported sampling frequencies: 44.1/48/88.2/96/176.4/192kHz
Supported bit depth: 16/24bits
Coaxial (cinch)
Optical (Toslink™)
Amplifier and power supply
Standby power supply for low power consumption in standby mode < 0,5 watts
Discrete Class A/B power amplifier
Shielded toroidal transformer
Elaborate mains adapter with separately stabilised supply voltage for the individual circuits
High-capacity filter/electrolytic capacitors
Standby power supply for low power consumption in standby mode
Bluetooth® input
Bluetooth® streaming (5.0) with the high-end audio standard Qualcomm® aptX™
HDMI®
HDMI with ARC and CEC function (volume can be controlled via TV remote control)
FM/DAB-Tuner
Digital DAB/DAB+ tuner
FM tuner
RDS/radio text function
40 programmable station presets each for DAB/DAB+ and FM
Automatic scanning function (FM)
Station search (DAB)
Highlights
Headphone output with high-quality 6.3 mm jack socket
Stable feet with damping rubber insert
Solid aluminium controls
Speaker terminal with solid, insulated screw terminals that are capable of accommodating large cable cross-sections
System remote control for all functions
Readable, two-line clear text display with adjustable brightness (3 stages)
Sturdy full-metal enclosure with solid, brushed aluminium front
Preamplifier
Additional 3.5 mm audio input on the front panel for connecting portable devices
Preselected and burned-in tubes
MM-phono preamplifier with low-noise operational amplifiers and subsonic filters
Dimensions
Main unit (WxHxD): 433 x 116 x 300 mm
Incl. controls and connectors (WxHxD): 433 x 116 x 345 mm
Remote control (WxHxD): 45 x 175 x 20 mm
Weight
7,6 kg
